1998 Catera

1998 Catera

In its sophomore year, the Catera received several upgrades.

STYLE

Model Style Number Body Type Seating Factory Price Shipping Weight Production Total
VR5 R69
Catera 4-door Sedan

4-door Sedan

5 29995 3770 N/A

ENGINE

1998 Catera

1998 Catera

Engine type 54-degree, dual overhead cam V-6
Block Cast iron
Cylinder heads aluminum
Displacement 181 cu. in (3.0 liters)
Bore & Stroke 3.40 x 3.40 in
Compression ratio 10.0:1
Brake horsepower 200 @ 6000 rpm
Torque 192 lb-ft @ 3600 rpm
Fuel supply Variable Dual-Ram induction system

CHASSIS

1998 Catera

1998 Catera

Wheelbase 107.4 in
Overall length 194.0 in
Height 56.3 in
Width 70.3 in
Front tread 59.3 in
Rear tread 59.8 in
Standard Tires Goodyear Eagle RS-a P225/55HR16

DRIVETRAIN

1998 Catera

1998 Catera

Transmission 4L30-E electronically controlled four-speed automatic transmission with overdrive
Steering Recirculating ball, speed sensitive
Front suspension MacPherson strut, lower control arms w/hydro bushing, coil spring, and stabilizer bar, gas preloaded dampers
Rear suspension Multi-link, coil spring and stabilizer bar, gas preloaded dampers
Brakes dual circuit front and rear disc w/Bosch anti-lock braking system
Body construction integral body-frame
Fuel tank 18.0 gal

OPTIONS

1998 Catera

1998 Catera

Heated seats $400
Bose sound system $973
Electric Sunroof $995
Power rear sunshade $295
Five-Spoke Chrome Wheels $795
